VSONO-PR1 Wireless Phased Array Color Doppler Ultrasound Scanner
A compact electronic phased-array probe for cardiac and transcranial imaging, with five imaging modes and wireless connection to compatible iOS, Android and Windows devices.
- Electronic phased array64 channels · 80° display angle
- Cardiac & transcranial2.5 / 2.8 / 3.6 MHz
- Five imaging modesB · M · Color · PW · PDI
- Connected workflow
iOS
Android
Windows
Included
Under return policy
No subscription
Delivery available internationally
Delivery estimate confirmed for your destination at checkout
Cardiac imaging, wherever care happens.
The VSONO-PR1 is a pocket-sized wireless phased-array Color Doppler ultrasound scanner designed for cardiac, transcranial and point-of-care examinations. Its compact probe connects to a compatible smart device for a mobile imaging workflow.
With B-mode, M-mode, Color Doppler, PW and PDI imaging, the PR1 supports cardiac assessment and selected vascular applications in clinics, emergency settings and bedside workflows.
Five imaging modes for cardiac assessment
B-mode
Two-dimensional grayscale imaging for cardiac anatomy and structural assessment.
M-mode
Motion-mode display for evaluating movement of cardiac structures over time.
Color Doppler
Color flow visualization to support assessment of blood-flow direction and patterns.
PW Doppler
Pulsed-wave Doppler for sampling flow velocity at a selected location.
Power Doppler
Power Doppler imaging for displaying Doppler signal intensity.
VSONO-PR1 technical specifications
| Probe type | Electronic phased array |
|---|---|
| Channels | 64 |
| Frequency | Cardiac central 2.8 MHz · reverse harmonic 3.6 MHz · transcranial fundamental 2.5 MHz |
| Imaging modes | B · B/M · Color Doppler · PW · PDI |
| Display angle | 80° |
| Display depth | 90 / 130 / 160 / 190 mm |
| Frame rate | 15–20 fps |
| Measurements | Length · Area · Angle · Cardiac functions |
| Connectivity | Wireless Wi-Fi |
| Dimensions | 140 × 60 × 20 mm |
| Weight | Approx. 120 g |
| Battery | Up to 1.5 hours continuous scanning |
| Charging | USB cable |
| Compatible platforms | iOS · Android · Windows |
Certifications and quality marks
CE
ISO 13485
EU MDRPortable cardiac and point-of-care workflows
Cardiology
Cardiac ultrasound examinations and echocardiographic assessment.
Emergency medicine
Portable imaging support in bedside and point-of-care workflows.
Transcranial imaging
Transcranial examinations using the specified 2.5 MHz fundamental frequency.
Vascular assessment
Selected vascular examinations using the available Doppler modes and measurement tools.
Wireless compatibility and app access
Connect the scanner wirelessly to a supported device and use the scanning app to view, store and review examinations. App availability and device requirements may vary by operating system version.
Frequently asked questions
What type of ultrasound probe is the VSONO-PR1?
It is an electronic phased-array wireless ultrasound probe designed for cardiac and transcranial imaging.
Which imaging modes does it support?
The listed modes are B-mode, M-mode, Color Doppler, PW Doppler and PDI.
What frequencies are available?
2.8 MHz cardiac central frequency, 3.6 MHz cardiac reverse harmonic and 2.5 MHz transcranial fundamental frequency.
What depth settings are available?
The listed display depth settings are 90, 130, 160 and 190 mm.
Which devices are compatible?
The product is listed as compatible with iOS, Android and Windows. Confirm app and device requirements with our team if you have a specific device.
How long does the battery last?
The product data lists up to 1.5 hours of continuous scanning. Actual runtime may vary with use and settings.
Is the scanner suitable for mobile examinations?
Yes. The compact 120 g probe and wireless workflow are designed for portable and bedside use.
What is included in the box?
The listed package includes one VSONO-PR1 phased-array wireless ultrasound scanner and one charger.
Need help choosing the right cardiac ultrasound scanner?
Contact our team with your intended examinations and compatible device model. We can help confirm the PR1 configuration and answer technical questions before you order.
